Draft2D The architectural survey, from your phone to CAD.
Measure the wall faces one after another: Draft2D draws the plan as you survey it and delivers it as a DXF, ready for CAD.
How it works
-
Draw
Tap Draw and enter the face measurements one after another. Every wall comes from what you measured, with no guesswork.
-
Complete
Close the room, add doors, windows, hatches, photos and the job's data.
-
Deliver
Export the DXF, the PDF to scale and the room schedule, and share them in one step.
Strengths
-
Walls as you measure them
Every measured face is a wall; thicknesses, junctions and arcs follow from the measurements.
-
Doors and windows with their jambs
Hinged, sliding or an opening without a door; windows with their sill; every opening with its measured depth.
-
Rooms and schedule
Net areas, perimeters, heights and volumes in a schedule you export as PDF and CSV.
-
DXF ready for CAD
Separate layers for walls, openings, rooms, hatches and furniture. Opens in AutoCAD and in every CAD.
-
PDF to scale and photos
An A4 sheet with a title block and a standard scale; photos attached to rooms, doors and walls, all inside the survey file.
-
Furnishing and five languages
A catalog with plan symbols, corner pieces, position lock. The app speaks Italian, English, German, French and Spanish.
Ready for the next site visit.
